DP200 BT & RJ Series


产品名称：DP200 BT & RJ Series
产品编号：9316-481
产品型号：DP200/BT,DP200/RJ,DP200/BT/RFI,DP200/RJ/RFI
更新时间：2009.12.03
出品厂家：英国MTL浪涌防雷保护器
浏览次数：34

DP200 BT & RJ Series

Specifi cation
All fi gures typical at 77°F (25°C) unless otherwise stated
Maximum discharge current
10kA (8/20μs)
Primary protector rating
10kV (10/700μs)
Leakage current
10μA at working voltage
Working voltage
162V
Max. continuous operating voltage
175V
Ringer Equivalence Number (REN)
0
Ambient temperature limits
-40°F to +158°F - working and storage
(40°C to +70°C) - working and storage
Humidity
5% to 95% RH (non-condensing)
Casing
Plastic ABS - VO IP50 Rated
Weight
4.41 oz (125g) nominal

Typical values DP200/BT&DP200/RJ DP200/BT/RFI&DP200/RJ/RFI
Line resistance
Limiting voltage
6kV/3kA
5kV/125A
Bandwidth (600 ohms)
Max stopband attenuation
Capacitance
line to line
line to earth
Insertion loss
@ 300Hz
@3400Hz
Line balance 300-3400Hz		 5 ohms

375V
205V
6MHz
not applicable

<200 pF
<150 pF

0.06dB
0.12 dB
betterthan 46dB		 10 ohms maximum

250V
205V
43kHz
65dB

<1.5 nF
<150 pF

0.06dB
0dB
better than 46dB
